Specifiche dettagliate di Pro WS X570-ACE Specifiche Generali，CPU:AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,* Refer to www. Asus. Com for CPU support list,* Due to CPU limitation, CPU cores supported varies by processors.、CPU:AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,* Refer to www.

Asus. Com for CPU support list,* Due to CPU limitation, CPU cores supported varies by processors.、Chipset:AMD X570、Chipset:AMD X570、Memoria: 3rd Gen AMD Ryzen™ Processors ,4 x DIMM, Max. 128GB, DDR4 MHz Un-buffered Memory *, 2nd Gen AMD Ryzen™ Processors , 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors ,4 x DIMM, Max. 128GB, DDR4 MHz Un-buffered Memory,Dual Channel Memory Architecture,ECC Memory (ECC mode) support varies by CPU.,* Refer to www. Asus. Com for the Memory QVL (Qualified Vendors Lists).,* The maximum memory capacity supported vary depending on the CPU you installed.、Memoria: 3rd Gen AMD Ryzen™ Processors ,4 x DIMM, Max. 128GB, DDR4 MHz Un-buffered Memory *, 2nd Gen AMD Ryzen™ Processors , 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors ,4 x DIMM, Max. 128GB, DDR4 MHz Un-buffered Memory,Dual Channel Memory Architecture,ECC Memory (ECC mode) support varies by CPU.,* Refer to www. Asus. Com for the Memory QVL (Qualified Vendors Lists).,* The maximum memory capacity supported vary depending on the CPU you installed.、Grafica:Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,VGA output support : HDMI port,- Supports HDMI 1. 4b with max. Resolution 4096 x 2160 @ 24 Hz,- Supports DisplayPort 1. 2 with max. Resolution 4096 x 2160 @ 60 Hz、Grafica:Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,VGA output support : HDMI port,- Supports HDMI 1. 4b with max. Resolution 4096 x 2160 @ 24 Hz,- Supports DisplayPort 1. 2 with max. Resolution 4096 x 2160 @ 60 Hz、Supporto Multi-GPU: 3rd and 2nd Gen AMD Ryzen™ Processors ,Supports NVIDIA® 2-Way SLI® Technology,Supports AMD 3-Way CrossFireX™ Technology、Supporto Multi-GPU: 3rd and 2nd Gen AMD Ryzen™ Processors ,Supports NVIDIA® 2-Way SLI® Technology,Supports AMD 3-Way CrossFireX™ Technology、Slot di Espansione:2 x PCIe 4. 0 x16 (x16 or dual x8),2 x PCIe 3. 0 x16 (x16 or dual x8),1 x PCIe 3. 0 x16 (x8 mode), AMD X570 chipset ,1 x PCIe 4. 0 x16 (x8 mode),1 x PCIe 4. 0 x1、Slot di Espansione:2 x PCIe 4. 0 x16 (x16 or dual x8),2 x PCIe 3. 0 x16 (x16 or dual x8),1 x PCIe 3. 0 x16 (x8 mode), AMD X570 chipset ,1 x PCIe 4. 0 x16 (x8 mode),1 x PCIe 4. 0 x1、Storage: 3rd Gen AMD Ryzen™ Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4. 0 x4 and SATA modes) storage devices support, 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3. 0 x4 and SATA modes) storage devices support, AMD X570 chipset : ,1 x M. 2_2 socket 3, with M Key, Type 2242/2260/2280(PCIE 4. 0 x2) storage devices support,1 x U. 2 connector, support PCIe 3. 0 x4 NVM Express storage,4 x SATA 6Gb/s port(s),Support Raid 0, 1, 10、Storage: 3rd Gen AMD Ryzen™ Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4. 0 x4 and SATA modes) storage devices support, 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3. 0 x4 and SATA modes) storage devices support, AMD X570 chipset : ,1 x M. 2_2 socket 3, with M Key, Type 2242/2260/2280(PCIE 4. 0 x2) storage devices support,1 x U. 2 connector, support PCIe 3. 0 x4 NVM Express storage,4 x SATA 6Gb/s port(s),Support Raid 0, 1, 10、LAN:Realtek® RTL8117,Intel® I211-AT,ASUS Turbo LAN Utility,ASUS LAN Guard、LAN:Realtek® RTL8117,Intel® I211-AT,ASUS Turbo LAN Utility,ASUS LAN Guard、Audio:Realtek® S1200A8-Channel High Definition Audio CODEC *,- Supports : Jack-detection, Front Panel Jack-retasking,- Front panel audio connector (AAFP), Audio Feature : ,- Optical S/PDIF out port(s) at back panel,- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference,- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals,- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- Unique de-pop circuit: Reduces start-up popping noise to audio outputs,- EMI protection cover to prevent electrical noise to affect the amplifier quality,Separate layer for left and right track, ensuring both sound deliver equal quality,* Choose the chassis with HD audio module in front panel to support 8-channel audio output.、Audio:Realtek® S1200A8-Channel High Definition Audio CODEC *,- Supports : Jack-detection, Front Panel Jack-retasking,- Front panel audio connector (AAFP), Audio Feature : ,- Optical S/PDIF out port(s) at back panel,- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference,- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals,- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- Unique de-pop circuit: Reduces start-up popping noise to audio outputs,- EMI protection cover to prevent electrical noise to affect the amplifier quality,Separate layer for left and right track, ensuring both sound deliver equal quality,* Choose the chassis with HD audio module in front panel to support 8-channel audio output.、Porte USB: 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : ,3 x USB 3. 2 Gen 1 port(s) (2 at back panel, blue, Type-A *, 1 at mid-board),5 x USB 3. 2 Gen 2 port(s) (4 at back panel, teal blue, Type-A, 1 x Type-C), AMD X570 chipset : ,4 x USB 2. 0 port(s) (4 at mid-board),* The USB ports under the LAN port can run at USB 3. 2 Gen 2 speeds with 3rd Gen AMD Ryzen™ Processors、Porte USB: 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : ,3 x USB 3. 2 Gen 1 port(s) (2 at back panel, blue, Type-A *, 1 at mid-board),5 x USB 3. 2 Gen 2 port(s) (4 at back panel, teal blue, Type-A, 1 x Type-C), AMD X570 chipset : ,4 x USB 2. 0 port(s) (4 at mid-board),* The USB ports under the LAN port can run at USB 3. 2 Gen 2 speeds with 3rd Gen AMD Ryzen™ Processors、Workstation Feature:ProCool Power Connector,ASUS Control Center (ACC)、Workstation Feature:ProCool Power Connector,ASUS Control Center (ACC)、Caratteristiche Speciali: 5-Way Optimization by Dual Intelligent Processors 5 ,- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, and Turbo App, Fan Xpert4 ,- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control, ASUS 5X Protection III : - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!,- ASUS Overvoltage Protection: World-class circuit-protecting power design,- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!,- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention,- ASUS ESD Guards - Enhanced ESD protection, ASUS SafeSlot - Protect your graphics card Investment, ASUS OptiMem： ,- Improved DDR4 Stability, ASUS EPU : ,- EPU, ASUS Exclusive Features :,- OptiMem,- AI Suite 3,- Ai Charger,- ESD Guards,- Turbo LAN,- Armoury Crate,- ASUS NODE : hardware control interface, ASUS Quiet Thermal Solution :,- Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan and PCH Heatsink,- ASUS Fan Xpert 4, ASUS EZ DIY : ,- ASUS CrashFree BIOS 3,- ASUS EZ Flash 3,- ASUS UEFI BIOS EZ Mode, ASUS Q-Design : ,- ASUS Q-Shield,- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED),- ASUS Q-Slot,- ASUS Q-DIMM、Caratteristiche Speciali: 5-Way Optimization by Dual Intelligent Processors 5 ,- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Expert 4, and Turbo App, Fan Xpert4 ,- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control, ASUS 5X Protection III : - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!,- ASUS Overvoltage Protection: World-class circuit-protecting power design,- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!,- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention,- ASUS ESD Guards - Enhanced ESD protection, ASUS SafeSlot - Protect your graphics card Investment, ASUS OptiMem： ,- Improved DDR4 Stability, ASUS EPU : ,- EPU, ASUS Exclusive Features :,- OptiMem,- AI Suite 3,- Ai Charger,- ESD Guards,- Turbo LAN,- Armoury Crate,- ASUS NODE : hardware control interface, ASUS Quiet Thermal Solution :,- Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan and PCH Heatsink,- ASUS Fan Xpert 4, ASUS EZ DIY : ,- ASUS CrashFree BIOS 3,- ASUS EZ Flash 3,- ASUS UEFI BIOS EZ Mode, ASUS Q-Design : ,- ASUS Q-Shield,- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED),- ASUS Q-Slot,- ASUS Q-DIMM、Porte I/O Posteriori:1 x DisplayPort,1 x HDMI,2 x LAN (RJ45) port(s),1 x Optical S/PDIF out,5 x Audio jack(s),2 x USB 3. 2 Gen 1 (up to 5Gbps) ports Type-A,4 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-A *),1 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-C)、Porte I/O Posteriori:1 x DisplayPort,1 x HDMI,2 x LAN (RJ45) port(s),1 x Optical S/PDIF out,5 x Audio jack(s),2 x USB 3. 2 Gen 1 (up to 5Gbps) ports Type-A,4 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-A *),1 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-C)、I/O Interne:1 x PCH_FAN,2 x USB 2. 0 connector(s) support(s) additional 4 USB 2. 0 port(s),1 x M. 2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode),1 x M. 2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only),1 x SPI TPM header,1 x COM port(s) connector(s),4 x SATA 6Gb/s connector(s),1 x CPU Fan connector(s) (1 x 4-pin),1 x CPU OPT Fan connector(s) (1 x 4-pin),3 x Chassis Fan connector(s) (3 x 4-pin),1 x AIO_PUMP connector (1 x 4-pin),1 x S/PDIF out header(s),1 x 24-pin EATX Power connector(s),1 x 8-pin ATX 12V Power connector(s),1 x 4-pin ATX 12V Power connector(s),1 x Front panel audio connector(s) (AAFP),1 x System panel(s),1 x Clear CMOS jumper(s),1 x U. 2 Connector (support U. 2 NVMe device),2 x USB 3. 2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports、I/O Interne:1 x PCH_FAN,2 x USB 2. 0 connector(s) support(s) additional 4 USB 2. 0 port(s),1 x M. 2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode),1 x M. 2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (PCIE mode only),1 x SPI TPM header,1 x COM port(s) connector(s),4 x SATA 6Gb/s connector(s),1 x CPU Fan connector(s) (1 x 4-pin),1 x CPU OPT Fan connector(s) (1 x 4-pin),3 x Chassis Fan connector(s) (3 x 4-pin),1 x AIO_PUMP connector (1 x 4-pin),1 x S/PDIF out header(s),1 x 24-pin EATX Power connector(s),1 x 8-pin ATX 12V Power connector(s),1 x 4-pin ATX 12V Power connector(s),1 x Front panel audio connector(s) (AAFP),1 x System panel(s),1 x Clear CMOS jumper(s),1 x U. 2 Connector (support U. 2 NVMe device),2 x USB 3. 2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports、Accessori:User´s manual,I/O Shield,4 x SATA 6Gb/s cable(s),1 x M. 2 Screw Package,1 x Supporting DVD,1 x ASUS VGA Holder、Accessori:User´s manual,I/O Shield,4 x SATA 6Gb/s cable(s),1 x M. 2 Screw Package,1 x Supporting DVD,1 x ASUS VGA Holder、BIOS:256 Mb Flash ROM, UEFI AMI BIOS, PnP, SMBIOS 3. 2, ACPI 6. 0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information、BIOS:256 Mb Flash ROM, UEFI AMI BIOS, PnP, SMBIOS 3. 2, ACPI 6. 0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information、Gestibilità:WOL by PME, PXE、Gestibilità:WOL by PME, PXE、Sistema Operativo:Windows® 10 64-bit、Sistema Operativo:Windows® 10 64-bit、Dimensioni Scheda:ATX Form Factor,12. 0 inch x 9. 6 inch ( 30. 5 cm x 24. 4 cm )、Dimensioni Scheda:ATX Form Factor,12. 0 inch x 9. 6 inch ( 30. 5 cm x 24. 4 cm )…
