PRIME X570-PRO - Specifiche Generali｜Schede Madri｜ASUS Italia AMD AM4 – 10953

Specifiche dettagliate di PRIME X570-PRO Specifiche Generali，CPU:AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,* Refer to www. Asus. Com for CPU support list,* Due to CPU limitation, CPU cores supported varies by processors.、CPU:AMD AM4 Socket 3rd and 2nd AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,* Refer to www.

Asus. Com for CPU support list,* Due to CPU limitation, CPU cores supported varies by processors.、Chipset:AMD X570、Chipset:AMD X570、Memoria:4 x DIMM, Max. 128GB, DDR4 4400(O. C)/4266(O. C.)/4133(O. C.)/4000(O. C.)/3866(O. C.)/3733(O. C.)/3600(O. C.)/3466(O. C.)/3400(O. C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory,4 x DIMM, Max. 128GB, DDR4 3600(O. C.)/3466(O. C.)/3400(O. C.)/3200(O. C.)/3000(O. C.)/2933/2800/2666/2400/2133 MHz Un-buffered Memory,4 x DIMM, Max. 128GB, DDR4 3200(O. C.)/3000(O. C.)/2933/2800/2666/2400/2133 MHz Un-buffered Memory, 3rd Gen AMD Ryzen™ Processors , 2nd Gen AMD Ryzen™ Processors , 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors ,Dual Channel Memory Architecture,ECC Memory (ECC mode) support varies by CPU.,* Refer to www. Asus. Com for the Memory QVL (Qualified Vendors Lists).,* The maximum memory capacity supported vary depending on the CPU you installed.、Memoria:4 x DIMM, Max. 128GB, DDR4 4400(O. C)/4266(O. C.)/4133(O. C.)/4000(O. C.)/3866(O. C.)/3733(O. C.)/3600(O. C.)/3466(O. C.)/3400(O. C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory,4 x DIMM, Max. 128GB, DDR4 3600(O. C.)/3466(O. C.)/3400(O. C.)/3200(O. C.)/3000(O. C.)/2933/2800/2666/2400/2133 MHz Un-buffered Memory,4 x DIMM, Max. 128GB, DDR4 3200(O. C.)/3000(O. C.)/2933/2800/2666/2400/2133 MHz Un-buffered Memory, 3rd Gen AMD Ryzen™ Processors , 2nd Gen AMD Ryzen™ Processors , 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors ,Dual Channel Memory Architecture,ECC Memory (ECC mode) support varies by CPU.,* Refer to www. Asus. Com for the Memory QVL (Qualified Vendors Lists).,* The maximum memory capacity supported vary depending on the CPU you installed.、Grafica:- Supports HDMI 2. 0b with maximum resolution of 4096 x 2160 @ 60 Hz,Multi-VGA output support : HDMI/DisplayPort ports,Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,- Supports DisplayPort 1. 2 with max. Resolution 4096 x 2160 @ 60 Hz、Grafica:- Supports HDMI 2. 0b with maximum resolution of 4096 x 2160 @ 60 Hz,Multi-VGA output support : HDMI/DisplayPort ports,Integrated Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors,- Supports DisplayPort 1. 2 with max. Resolution 4096 x 2160 @ 60 Hz、Supporto Multi-GPU:Supports AMD 2-Way CrossFireX™ Technology, 3rd and 2nd Gen AMD Ryzen™ Processors ,Supports NVIDIA® 2-Way SLI® Technology,Supports AMD 3-Way CrossFireX™ Technology、Supporto Multi-GPU:Supports AMD 2-Way CrossFireX™ Technology, 3rd and 2nd Gen AMD Ryzen™ Processors ,Supports NVIDIA® 2-Way SLI® Technology,Supports AMD 3-Way CrossFireX™ Technology、Slot di Espansione:1 x PCIe 4. 0 x16 (max at x4 mode),3 x PCIe 4. 0 x1,2 x PCIe 4. 0 x16 (x16 or dual x8),2 x PCIe 3. 0 x16 (x16 or dual x8),1 x PCIe 3. 0 x16 (x8 mode), AMD X570 chipset 、Slot di Espansione:1 x PCIe 4. 0 x16 (max at x4 mode),3 x PCIe 4. 0 x1,2 x PCIe 4. 0 x16 (x16 or dual x8),2 x PCIe 3. 0 x16 (x16 or dual x8),1 x PCIe 3. 0 x16 (x8 mode), AMD X570 chipset 、Storage:6 x SATA 6Gb/s port(s),1 x M. 2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4. 0 x4 and SATA modes) storage devices support, 3rd Gen AMD Ryzen™ Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4. 0 x4 and SATA modes) storage devices support, 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3. 0 x4 and SATA modes) storage devices support, AMD X570 chipset : ,Support Raid 0, 1, 10、Storage:6 x SATA 6Gb/s port(s),1 x M. 2_2 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4. 0 x4 and SATA modes) storage devices support, 3rd Gen AMD Ryzen™ Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4. 0 x4 and SATA modes) storage devices support, 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : ,1 x M. 2_1 socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3. 0 x4 and SATA modes) storage devices support, AMD X570 chipset : ,Support Raid 0, 1, 10、LAN:Intel® I211-AT,ASUS LAN Guard、LAN:Intel® I211-AT,ASUS LAN Guard、Audio:Realtek® S1220A8-Channel High Definition Audio CODEC featuring Crystal Sound 3,- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers,- High quality120dBSNR stereo playback outputand113dBSNR recording input(Line-in),- Supports up to 32-Bit/192kHz playback *,* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.,- Impedance sense for front and rear headphone outputs,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking,- Front panel audio connector (AAFP), Audio Feature : ,- Optical S/PDIF out port(s) at back panel,- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference,- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals,- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- EMI protection cover to prevent electrical noise to affect the amplifier quality、Audio:Realtek® S1220A8-Channel High Definition Audio CODEC featuring Crystal Sound 3,- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers,- High quality120dBSNR stereo playback outputand113dBSNR recording input(Line-in),- Supports up to 32-Bit/192kHz playback *,* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for 8-Channel audio.,- Impedance sense for front and rear headphone outputs,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking,- Front panel audio connector (AAFP), Audio Feature : ,- Optical S/PDIF out port(s) at back panel,- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference,- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals,- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- EMI protection cover to prevent electrical noise to affect the amplifier quality、Porte USB:4 x USB 3. 2 Gen 1 port(s) (4 at back panel, blue, Type-A),4 x USB 3. 2 Gen 2 port(s) (4 at back panel, teal blue, 3 x Type-A+1 x Type-C),1 x USB 3. 2 Gen 2 front panel connector port(s),2 x USB 3. 2 Gen 1 port(s) (2 at mid-board), 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : , AMD X570 chipset : ,4 x USB 2. 0 port(s) (4 at mid-board)、Porte USB:4 x USB 3. 2 Gen 1 port(s) (4 at back panel, blue, Type-A),4 x USB 3. 2 Gen 2 port(s) (4 at back panel, teal blue, 3 x Type-A+1 x Type-C),1 x USB 3. 2 Gen 2 front panel connector port(s),2 x USB 3. 2 Gen 1 port(s) (2 at mid-board), 3rd and 2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors : , AMD X570 chipset : ,4 x USB 2. 0 port(s) (4 at mid-board)、Caratteristiche Speciali:- 5-Way Optimization tuning key perfectly consolidates TPU Insight, EPU Guidance, DIGI+ VRM, Fan Expert 4, and Turbo App, DIGI+ VRM: Digital power design with Dr. MOS , EPU Guidance , TPU Insight , Turbo App: system performance tuning, network priority, and audio scene configuration for selected applications., ASUS 5X Protection III : - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage,- ASUS DIGI+ VRM - Digital power design with Dr. MOS,- Pre-mounted I/O Shield,- ASUS Q-Connector,- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!, AURA : ,- Aura Lighting Control,- Aura RGB Strip Headers,- Addressable Gen 2 Header,- Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan, PCH and M. 2 Heatsink, 5-Way Optimization by Dual Intelligent Processors 5 , Fan Xpert4 ,- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control,- ASUS Overvoltage Protection: World-class circuit-protecting power design,- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!,- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention,- ASUS ESD Guards - Enhanced ESD protection, ASUS SafeSlot - Protect your graphics card Investment, ASUS OptiMem： ,- Improved DDR4 Stability, ASUS Exclusive Features :,- AI Suite 3,- Ai Charger,- Turbo LAN,- Armoury Crate, ASUS Quiet Thermal Solution :,- ASUS Fan Xpert 4, ASUS EZ DIY : ,- ASUS CrashFree BIOS 3,- ASUS EZ Flash 3,- ASUS UEFI BIOS EZ Mode, ASUS Q-Design : ,- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED),- ASUS Q-Slot,- ASUS Q-DIMM、Caratteristiche Speciali:- 5-Way Optimization tuning key perfectly consolidates TPU Insight, EPU Guidance, DIGI+ VRM, Fan Expert 4, and Turbo App, DIGI+ VRM: Digital power design with Dr. MOS , EPU Guidance , TPU Insight , Turbo App: system performance tuning, network priority, and audio scene configuration for selected applications., ASUS 5X Protection III : - ASUS SafeSlot Core: Fortified PCIe Slot prevents damage,- ASUS DIGI+ VRM - Digital power design with Dr. MOS,- Pre-mounted I/O Shield,- ASUS Q-Connector,- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!, AURA : ,- Aura Lighting Control,- Aura RGB Strip Headers,- Addressable Gen 2 Header,- Stylish Design: MOS Heat-sink with dual thermal pads design, PCH Fan, PCH and M. 2 Heatsink, 5-Way Optimization by Dual Intelligent Processors 5 , Fan Xpert4 ,- Fan Xpert 4 featuring Fan Auto Tuning function and multiple thermistors selection for optimized system cooling control,- ASUS Overvoltage Protection: World-class circuit-protecting power design,- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!,- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage prevention,- ASUS ESD Guards - Enhanced ESD protection, ASUS SafeSlot - Protect your graphics card Investment, ASUS OptiMem： ,- Improved DDR4 Stability, ASUS Exclusive Features :,- AI Suite 3,- Ai Charger,- Turbo LAN,- Armoury Crate, ASUS Quiet Thermal Solution :,- ASUS Fan Xpert 4, ASUS EZ DIY : ,- ASUS CrashFree BIOS 3,- ASUS EZ Flash 3,- ASUS UEFI BIOS EZ Mode, ASUS Q-Design : ,- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED),- ASUS Q-Slot,- ASUS Q-DIMM、Porte I/O Posteriori:4 x USB 3. 2 Gen 1 (up to 5Gbps) ports Type-A,3 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-A),1 x PS/2 keyboard/mouse combo port(s),1 x LAN (RJ45) port(s),1 x DisplayPort,1 x HDMI,1 x Optical S/PDIF out,5 x Audio jack(s),1 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-C)、Porte I/O Posteriori:4 x USB 3. 2 Gen 1 (up to 5Gbps) ports Type-A,3 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-A),1 x PS/2 keyboard/mouse combo port(s),1 x LAN (RJ45) port(s),1 x DisplayPort,1 x HDMI,1 x Optical S/PDIF out,5 x Audio jack(s),1 x USB 3. 2 Gen 2 (up to 10Gbps) ports (Type-C)、I/O Interne:2 x M. 2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode),1 x Water Pump header (4-pin),6 x SATA 6Gb/s connector(s),1 x PCH_FAN (1 x 4-pin),2 x Aura RGB Strip Headers,1 x Power-on button(s),1 x Node Connector(s),1 x T_Sensor Connector,1 x USB 3. 2 Gen 2 (up to 10Gbps) connector,1 x Addressable Gen 2 header(s),1 x USB 3. 2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports,2 x USB 2. 0 connector(s) support(s) additional 4 USB 2. 0 port(s),1 x SPI TPM header,1 x COM port(s) connector(s),1 x CPU Fan connector(s) (1 x 4-pin),1 x CPU OPT Fan connector(s) (1 x 4-pin),3 x Chassis Fan connector(s) (3 x 4-pin),1 x AIO_PUMP connector (1 x 4-pin),1 x 24-pin EATX Power connector(s),1 x 8-pin ATX 12V Power connector(s),1 x 4-pin ATX 12V Power connector(s),1 x Front panel audio connector(s) (AAFP),1 x System panel(s),1 x Clear CMOS jumper(s)、I/O Interne:2 x M. 2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & PCIE mode),1 x Water Pump header (4-pin),6 x SATA 6Gb/s connector(s),1 x PCH_FAN (1 x 4-pin),2 x Aura RGB Strip Headers,1 x Power-on button(s),1 x Node Connector(s),1 x T_Sensor Connector,1 x USB 3. 2 Gen 2 (up to 10Gbps) connector,1 x Addressable Gen 2 header(s),1 x USB 3. 2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports,2 x USB 2. 0 connector(s) support(s) additional 4 USB 2. 0 port(s),1 x SPI TPM header,1 x COM port(s) connector(s),1 x CPU Fan connector(s) (1 x 4-pin),1 x CPU OPT Fan connector(s) (1 x 4-pin),3 x Chassis Fan connector(s) (3 x 4-pin),1 x AIO_PUMP connector (1 x 4-pin),1 x 24-pin EATX Power connector(s),1 x 8-pin ATX 12V Power connector(s),1 x 4-pin ATX 12V Power connector(s),1 x Front panel audio connector(s) (AAFP),1 x System panel(s),1 x Clear CMOS jumper(s)、Accessori:1 x Q-connector(s) (1 in 1),1 x Extension cable for Addressable LED,2 x SATA 6Gb/s cable(s),User´s manual,1 x M. 2 Screw Package,1 x Supporting DVD、Accessori:1 x Q-connector(s) (1 in 1),1 x Extension cable for Addressable LED,2 x SATA 6Gb/s cable(s),User´s manual,1 x M. 2 Screw Package,1 x Supporting DVD、BIOS:256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3. 2, ACPI 6. 2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen,F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information、BIOS:256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3. 2, ACPI 6. 2, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen,F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence Detect) memory information、Sistema Operativo:Windows® 10 64-bit、Sistema Operativo:Windows® 10 64-bit、Dimensioni Scheda:ATX Form Factor,12. 0 inch x 9. 6 inch ( 30. 5 cm x 24. 4 cm )、Dimensioni Scheda:ATX Form Factor,12. 0 inch x 9. 6 inch ( 30. 5 cm x 24. 4 cm )…
