X99-E-10G WS - Specifiche Generali｜Schede Madri｜ASUS Italia Intel – 8822

Specifiche dettagliate di X99-E-10G WS Specifiche Generali，CPU:Build in Intel® Socket 2011-v3 Core™ i7/Core™ i7 X-Series Processors,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-1600 v3 product family,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-2600 v3 product family,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-1600 v4 product family,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-2600 v4 product family,Supports Intel® 14nm CPU,Supports Intel® Turbo Boost Max Technology 3. 0,* The Intel® Turbo Boost Technology 3. 0 Support Depends on the CPU types.,* Refer to www.

Asus. Com for CPU support list、CPU:Build in Intel® Socket 2011-v3 Core™ i7/Core™ i7 X-Series Processors,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-1600 v3 product family,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-2600 v3 product family,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-1600 v4 product family,Intel® Socket 2011-v3 for Intel® Xeon® processor E5-2600 v4 product family,Supports Intel® 14nm CPU,Supports Intel® Turbo Boost Max Technology 3. 0,* The Intel® Turbo Boost Technology 3. 0 Support Depends on the CPU types.,* Refer to www. Asus. Com for CPU support list、Chipset:Intel® X99、Chipset:Intel® X99、Memoria:8 x DIMM, Max. 128GB, DDR4 3333(O. C.)/3200(O. C.)/3000(O. C.)/2800(O. C.)/2666(O. C.)/2400(O. C.)/2133 MHz Non-ECC, Un-buffered Memory * 1 ,8 x DIMM, Max. 128GB, DDR4 2400/2133 MHz ECC, Un-buffered Memory * 2 ,8 x DIMM, Max. 128GB, DDR4 2400/2133 MHz ECC, Register Memory * 2 ,Quad Channel Memory Architecture,Supports Intel® Extreme Memory Profile (XMP),* Hyper DIMM support is subject to the physical characteristics of individual CPUs.,* Refer to www. Asus. Com for the Memory QVL (Qualified Vendors Lists).、Memoria:8 x DIMM, Max. 128GB, DDR4 3333(O. C.)/3200(O. C.)/3000(O. C.)/2800(O. C.)/2666(O. C.)/2400(O. C.)/2133 MHz Non-ECC, Un-buffered Memory * 1 ,8 x DIMM, Max. 128GB, DDR4 2400/2133 MHz ECC, Un-buffered Memory * 2 ,8 x DIMM, Max. 128GB, DDR4 2400/2133 MHz ECC, Register Memory * 2 ,Quad Channel Memory Architecture,Supports Intel® Extreme Memory Profile (XMP),* Hyper DIMM support is subject to the physical characteristics of individual CPUs.,* Refer to www. Asus. Com for the Memory QVL (Qualified Vendors Lists).、Supporto Multi-GPU:Supports NVIDIA® 4-Way SLI™ Technology,Supports AMD 4-Way CrossFireX Technology、Supporto Multi-GPU:Supports NVIDIA® 4-Way SLI™ Technology,Supports AMD 4-Way CrossFireX Technology、Slot di Espansione:7 x PCIe 3. 0/2. 0 x16 (single x16 or dual x16/x16 or triple x16/x16/x16 or quad x16/x16/x16/x16 or seven x16/x8/x8/x8/x8/x8/x8)、Slot di Espansione:7 x PCIe 3. 0/2. 0 x16 (single x16 or dual x16/x16 or triple x16/x16/x16 or quad x16/x16/x16/x16 or seven x16/x8/x8/x8/x8/x8/x8)、Storage: Intel® X99 chipset : * 3 ,1 x U. 2 connector* 4 ,,1 x M. 2 x4 Socket 3* 4 , , with M Key, type 2260/2280 storage devices support (PCIE mode),10 x SATA 6Gb/s port(s), * 5 ,Intel® Rapid Storage Technology supports* 6 、Storage: Intel® X99 chipset : * 3 ,1 x U. 2 connector* 4 ,,1 x M. 2 x4 Socket 3* 4 , , with M Key, type 2260/2280 storage devices support (PCIE mode),10 x SATA 6Gb/s port(s), * 5 ,Intel® Rapid Storage Technology supports* 6 、LAN:Intel® X550-AT2 10, 2 x Gigabit LAN ports、LAN:Intel® X550-AT2 10, 2 x Gigabit LAN ports、Audio:Realtek® ALC11508-Channel High Definition Audio CODEC featuring Crystal Sound 3,- High quality112dBSNR stereo playback output(Line-out at rear)and104dBSNR stereo playback input(Line-in),- Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound,- DTS Studio Sound,- BD Audio Layer Content Protection,- Top notch audio sensation delivers according to the audio configuration,- Audio amplifier: Provides the highest-quality sound for headphone and speakers,- DTS Connect,- Power pre-regulator: Reduces power input noise to ensure consistent performance,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, Audio Feature : ,- Optical S/PDIF out port(s) at back panel,- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals,- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- Unique de-pop circuit: Reduces start-up popping noise to audio outputs,Separate layer for left and right track, ensuring both sound deliver equal quality、Audio:Realtek® ALC11508-Channel High Definition Audio CODEC featuring Crystal Sound 3,- High quality112dBSNR stereo playback output(Line-out at rear)and104dBSNR stereo playback input(Line-in),- Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound,- DTS Studio Sound,- BD Audio Layer Content Protection,- Top notch audio sensation delivers according to the audio configuration,- Audio amplifier: Provides the highest-quality sound for headphone and speakers,- DTS Connect,- Power pre-regulator: Reduces power input noise to ensure consistent performance,- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, Audio Feature : ,- Optical S/PDIF out port(s) at back panel,- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals,- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity,- Unique de-pop circuit: Reduces start-up popping noise to audio outputs,Separate layer for left and right track, ensuring both sound deliver equal quality、Porte USB:8 x USB 3. 1 Gen 1 port(s) (4 at back panel, ), Intel® X99 chipset : , ASMedia® USB 3. 1 controller : ,4 x USB 2. 0/1. 1 port(s) (4 at mid-board),2 x USB 3. 1 Gen 2 port(s) (2 at back panel, , Type-A + USB Type-C TM )、Porte USB:8 x USB 3. 1 Gen 1 port(s) (4 at back panel, ), Intel® X99 chipset : , ASMedia® USB 3. 1 controller : ,4 x USB 2. 0/1. 1 port(s) (4 at mid-board),2 x USB 3. 1 Gen 2 port(s) (2 at back panel, , Type-A + USB Type-C TM )、Workstation Feature:7 x PCIe x 16 slot(s),ASUS PIKE SAS upgrade kit(Optional),ProCool Power Connector、Workstation Feature:7 x PCIe x 16 slot(s),ASUS PIKE SAS upgrade kit(Optional),ProCool Power Connector、Caratteristiche Speciali:- Industry leading Digital 8 Phase Power Design,- Industry leading Digital 4 Phase DRAM Power Design,- CPU Power Utility,- DRAM Power Utility,- USB 3. 1 Boost,- Push Notice, Media Streamer ,- Disk Unlocker,- Ai Charger+,- ASUS USB BIOS Flashback, ASUS TPU : ,- Auto Tuning,- MemOK!,- Precision Tweaker 2,- ASUS O. C. Tuner,- GPU Boost, ASUS Digital Power Design : ,- Crystal Sound 3,- ASUS Q-LED (CPU, VGA, Boot Device LED), Special Memory O. C. Design , Turbo App , M. 2 and U. 2 Onboard (The Latest Transfer Technology with up to 32Gb/s Data-transfer Speeds for M. 2 and U. 2) ,- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo Core App,- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface,- ASUS CrashFree BIOS,- ASUS EZ Flash,- ASUS Q-Connector,- ASUS Q-Code, 5-Way Optimization by Dual Intelligent Processors 5 , ASUS EPU : ,- EPU, ASUS Exclusive Features :,- AI Suite 3,- Turbo LAN, ASUS EZ DIY : ,- ASUS UEFI BIOS EZ Mode, ASUS Q-Design : ,- ASUS Q-Slot,- ASUS Q-DIMM、Caratteristiche Speciali:- Industry leading Digital 8 Phase Power Design,- Industry leading Digital 4 Phase DRAM Power Design,- CPU Power Utility,- DRAM Power Utility,- USB 3. 1 Boost,- Push Notice, Media Streamer ,- Disk Unlocker,- Ai Charger+,- ASUS USB BIOS Flashback, ASUS TPU : ,- Auto Tuning,- MemOK!,- Precision Tweaker 2,- ASUS O. C. Tuner,- GPU Boost, ASUS Digital Power Design : ,- Crystal Sound 3,- ASUS Q-LED (CPU, VGA, Boot Device LED), Special Memory O. C. Design , Turbo App , M. 2 and U. 2 Onboard (The Latest Transfer Technology with up to 32Gb/s Data-transfer Speeds for M. 2 and U. 2) ,- 5-Way Optimization tuning key perfectly consolidates TPU, EPU, DIGI+ VRM, Fan Xpert 4, and Turbo Core App,- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface,- ASUS CrashFree BIOS,- ASUS EZ Flash,- ASUS Q-Connector,- ASUS Q-Code, 5-Way Optimization by Dual Intelligent Processors 5 , ASUS EPU : ,- EPU, ASUS Exclusive Features :,- AI Suite 3,- Turbo LAN, ASUS EZ DIY : ,- ASUS UEFI BIOS EZ Mode, ASUS Q-Design : ,- ASUS Q-Slot,- ASUS Q-DIMM、Porte I/O Posteriori:8 x Audio jack(s),2 x Intel 10G LAN (BASE-T) Ports,2 x USB 3. 1 Type-A + USB Type-C TM ,4 x USB 3. 1 Gen 1 (blue),1 x Optical S/PDIF out、Porte I/O Posteriori:8 x Audio jack(s),2 x Intel 10G LAN (BASE-T) Ports,2 x USB 3. 1 Type-A + USB Type-C TM ,4 x USB 3. 1 Gen 1 (blue),1 x Optical S/PDIF out、I/O Interne:1 x M. 2 Socket 3 for M Key, type 2260/2280 devices,2 x Chassis Fan connector(s) (4 x -pin),1 x 6-pin EATX 12V_1 Power connector(s),1 x DRCT header(s),1 x SLI/CFX switch (2/3-WAY adjustments),1 x 3-pin CHASSIS(Chassis intrusion) connector,10 x SATA 6Gb/s connector(s),2 x 8-pin EATX 12V Power connector,2 x USB 3. 1 Gen 1 connector(s) support(s) additional 4 USB 3. 1 Gen 1 port(s) (19-pin),1 x RGB Header(s),1 x Front panel connector(s),1 x EZ XMP switch,1 x High AMP Fan Header,1 x MemOK! Button(s),1 x System panel(s) (Q-Connector),1 x CPU OV,1 x Water Pump header (4-pin),1 x TPM connector(s),1 x Power-on button(s),1 x Reset button(s),1 x T_Sensor Connector,1 x COM port header,2 x USB 2. 0 connector(s) support(s) additional 4 USB 2. 0 port(s),1 x CPU Fan connector(s) (1 x 4-pin),1 x CPU OPT Fan connector(s) (1 x 4-pin),1 x S/PDIF out header(s),1 x 24-pin EATX Power connector(s),1 x U. 2 Connector (support U. 2 NVMe device)、I/O Interne:1 x M. 2 Socket 3 for M Key, type 2260/2280 devices,2 x Chassis Fan connector(s) (4 x -pin),1 x 6-pin EATX 12V_1 Power connector(s),1 x DRCT header(s),1 x SLI/CFX switch (2/3-WAY adjustments),1 x 3-pin CHASSIS(Chassis intrusion) connector,10 x SATA 6Gb/s connector(s),2 x 8-pin EATX 12V Power connector,2 x USB 3. 1 Gen 1 connector(s) support(s) additional 4 USB 3. 1 Gen 1 port(s) (19-pin),1 x RGB Header(s),1 x Front panel connector(s),1 x EZ XMP switch,1 x High AMP Fan Header,1 x MemOK! Button(s),1 x System panel(s) (Q-Connector),1 x CPU OV,1 x Water Pump header (4-pin),1 x TPM connector(s),1 x Power-on button(s),1 x Reset button(s),1 x T_Sensor Connector,1 x COM port header,2 x USB 2. 0 connector(s) support(s) additional 4 USB 2. 0 port(s),1 x CPU Fan connector(s) (1 x 4-pin),1 x CPU OPT Fan connector(s) (1 x 4-pin),1 x S/PDIF out header(s),1 x 24-pin EATX Power connector(s),1 x U. 2 Connector (support U. 2 NVMe device)、Accessori:10 x SATA 6Gb/s cable(s),1 x Q-connector(s) (2 in 1),1 x SLI bridge(s),1 x COM port cable(s),1 x 3-Way SLI bridge(s),1 x 4-Way SLI bridge(s),1 x 2-port USB 2. 0 module(s),1 x Extension Cable for RGB strips (80 cm),User´s manual,I/O Shield,1 x Supporting DVD、Accessori:10 x SATA 6Gb/s cable(s),1 x Q-connector(s) (2 in 1),1 x SLI bridge(s),1 x COM port cable(s),1 x 3-Way SLI bridge(s),1 x 4-Way SLI bridge(s),1 x 2-port USB 2. 0 module(s),1 x Extension Cable for RGB strips (80 cm),User´s manual,I/O Shield,1 x Supporting DVD、BIOS:128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2. 7, WfM2. 0, SM BIOS 2. 7, ACPI 5. 0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information.、BIOS:128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2. 7, WfM2. 0, SM BIOS 2. 7, ACPI 5. 0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information.、Gestibilità:WfM 2. 0, DMI 2. 7, WOL by PME, PXE、Gestibilità:WfM 2. 0, DMI 2. 7, WOL by PME, PXE、Disco di Supporto:Drivers、ASUS Utilities、EZ Update 、Anti-virus software (OEM version)、Disco di Supporto:Drivers、ASUS Utilities、EZ Update 、Anti-virus software (OEM version)、Sistema Operativo:Windows® 8. 1 64-bit,Windows® 7 64-bit、Sistema Operativo:Windows® 8. 1 64-bit,Windows® 7 64-bit、Dimensioni Scheda:CEB Form Factor,12 inch x 10. 5 inch ( 30. 5 cm x 26. 7 cm )、Dimensioni Scheda:CEB Form Factor,12 inch x 10. 5 inch ( 30. 5 cm x 26. 7 cm )、Ambiente:Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing)、Ambiente:Operation temperature: 10℃ ~ 35℃ Non operation temperature: -40℃ ~ 70℃ Non operation humidity: 20% ~ 90% ( Non condensing)、Note:*1 When installing Intel® Socket 2011-v3 Core™ i7/i7 X-Series Processors *2 When installing Intel® Xeon® E5-2600/1600 v4/v3 Processor *3 Intel® X99 Express Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology 14 support *4 Support on 40 Lane CPU *5 10 x SATA 6. 0 Gb/s ports* (6 x gray, 4 x black) *6 These functions will work depending on the CPU installed、Note:*1 When installing Intel® Socket 2011-v3 Core™ i7/i7 X-Series Processors *2 When installing Intel® Xeon® E5-2600/1600 v4/v3 Processor *3 Intel® X99 Express Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology 14 support *4 Support on 40 Lane CPU *5 10 x SATA 6. 0 Gb/s ports* (6 x gray, 4 x black) *6 These functions will work depending on the CPU installed…
